The 6th Axis CALSET Jig

Positioning Jig for 6th axis CALSET of VS-*** series robot.

Since the usage varies according to the robot type, please refer to each procedure.

• 6th-Axis CALSET Position (Standard Type Robot, Standard Flange)
• 6th-Axis CALSET Position (Communication Interface Flange-A)
• 6th-Axis CALSET Position (Dust- & Splash-proof Type and Protected Type)
• 6th-Axis CALSET Position (Clean Room Type Robot)
